Universal 625–725 Product Specifications

Universal 625/725 is a 2-inch thick insulated steel garage door series designed for reliable daily operation, enhanced comfort, and a refined woodgrain appearance. Built with 25-gauge steel on the face and a 26-gauge steel backskin, these doors are engineered for strength, durability, and a tight seal at the section joints. In Vallejo, this series is a strong match for homeowners who want an insulated door with upgraded construction details, along with multiple panel designs ranging from traditional definition to beadboard styling. For selection guidance, sizing, and professional installation planning, R&S Erection of Vallejo can help you choose the right model and options for your opening and usage needs.

Product Overview for Universal 625/725

Universal Model 625/725
25-Gauge, 2″ Insulated Steel Door with Steel Backskin (R-value up to 9.0)
  • 2″ insulated sections – Built for stronger performance and improved comfort.
  • Steel front + steel back – Laminated construction supports long-term durability.
  • Woodgrain embossed texture – Adds visual depth and a refined finish.
  • Tongue-and-groove joints – Helps deliver a tighter, weather-focused section fit.
  • Multiple panel styles – Traditional definition, flush, and bead board options.

Features

Insulated Steel Construction (R-value up to 9.0)

A CFC-free polystyrene core laminated between steel skins helps improve comfort in attached garages and supports quieter operation.

Built-In Strength at Key Points

A reinforced aluminum bottom retainer is mechanically fastened and bonded to the bottom section, supporting a replaceable, UV-protected weather seal for additional protection.

Weather-Tight Section Joints

Tongue-and-groove meeting rails are designed to help reduce air and moisture intrusion at section connections.

Durable Finish and Surface Detail

Pre-painted steel skins feature a multi-coat rust protection system and a rotary embossed woodgrain texture, with pressed panel definition for enhanced exterior styling.

Specifications

Specification
Details
Series
Universal U625/725
Door construction
2" thick insulated sectional steel door
Section heights
21" and 18"
Steel skins
25-gauge face skin; 26-gauge backskin
Finish
Pre-painted white steel with rust protection system; woodgrain embossing
Panel definition
Traditional Definition (SP/LP), Flush (FL), Carriage Bead Board (U725)
Insulation core
CFC-free polystyrene core, laminated
Thermal performance
R-value up to 9.0
Joint design
Tongue-and-groove meeting rails
Bottom seal system
Reinforced aluminum retainer with replaceable UV-protected grooved weather seal
Standard widths
8', 9', 10', 12', 14', 15', 15'8", 16', 18'
Standard heights
6'0" through 14'0" (3" increments); additional heights available
Hinges
Hot dipped galvanized; wide body end roller hinges; interior hinges
Rollers
2" black nylon; optional white nylon
Warranty
Limited lifetime warranty (model-dependent coverage terms)

Options / Customization

  • Glass designs: Multiple decorative window design selections are available.
  • Decorative hardware: Upgrade appearance with matching accent hardware styles.
  • Color options: White, Sandstone, or Brown finishes may be available (some colors may require post-painting based on project requirements).
  • Hardware upgrades: Optional commercial-grade hinge packages, heavy-duty fixtures, upgraded rollers, inside slide lock, double lift handles, reinforced track options, and related upgrade components.

Our Garage Door Services in Vallejo

R&S Erection of Vallejo provides garage door installation, replacement, repair, tune-ups, and hardware support to help your system operate smoothly and safely. If you’re upgrading to Universal 625–725, we can also help you select the right insulated configuration, panel style, and hardware upgrades so your system delivers the comfort, durability, and appearance you want.
